61
Printer Setup and Operation
Load the Media
7/3/13 P1056468-002
4. Insert media into the printer. Follow the instructions for roll or fanfold media, as
appropriate.
Roll Media
Fanfold Media
a. Remove and discard any tags or labels that are
dirty or that are held by adhesives or tape.
a. Thread the fanfold media through the bottom
or rear slot.
Bottom Feed
Rear Feed
b. Pull out the media supply guide as far as it
goes.
b. Pull out the media supply guide as far as it
goes.

Table of Contents

Other manuals for Zebra 105SL Plus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra 105SL Plus and is the answer not in the manual?

Zebra 105SL Plus Specifications

General IconGeneral
Weight50 lbs / 22.7 kg
Humidity20-85% non-condensing
Print MethodThermal Transfer
Resolution203 dpi (8 dots/mm)
Max Print Width4.09 inches / 104 mm
Max Print Speed12 inches per second / 305 mm per second
Memory16 MB SDRAM, 8 MB Flash
Media Width0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media TypesContinuous, die-cut, black mark
Ribbon Width2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length1476'/450 m
ConnectivityParallel, Serial
Optional ConnectivityEthernet, Wireless
Power Requirements90-264 VAC; 48-62 Hz
Operating Temperature40°F to 105°F / 5°C to 40°C
Storage Temperature-40°F to 140°F / -40°C to 60°C
