Zebra 105SL Plus User Manual

87
Printer Configuration and Adjustment
Changing Printer Settings
7/3/13 P1056468-002
Backfeed
Sequence
This parameter sets when label backfeed occurs after a label is removed in some print
modes. It has no effect in Rewind mode. This setting is superseded by
~JS when received
as part of a label format.
Accepted values:
• AFTER (backfeed occurs immediately after the last
label is completed)
• OFF (no backfeed)
• BEFORE (backfeed occurs before the forward motion
of the first label)
• DEFAULT
Related ZPL command(s): ~JS
SGD command used:
none
Control panel menu item: BACKFEED on page 30
Printer web page:
View and Modify Printer Settings > Advanced Setup >
Backfeed
Label Top
Position
This parameter adjusts the print position vertically on the label. Positive numbers adjust the
label top position farther down the label (away from the printhead) by the specified number
of dots. Negative numbers adjust the position up the label (toward the printhead).
Accepted values:
–120 to 120
Related ZPL command(s): ^LT
SGD command used:
none
Control panel menu item: LABEL TOP on page 30
Printer web page:
View and Modify Printer Settings > General Setup >
Label Top
Label Left
Position
If necessary, shift the print position horizontally on the label. Positive numbers move the left
edge of the image toward the center of the label by the number of dots selected, while
negative numbers move the left edge of the image toward the left edge of the label.
Accepted values:
–9999 to 9999
Related ZPL command(s): ^LS
SGD command used:
none
Control panel menu item: LEFT POSITION on page 30
Printer web page:
View and Modify Printer Settings > Advanced Setup >
Left Position
Head Test
Count
The printer periodically performs a test of the printhead functionality. This parameter
establishes how many labels are printed between these internal tests.
Accepted values:
0000 (disables the test) to 9999
Related ZPL command(s): ^JT
SGD command used:
none
Control panel menu item: HEAD TEST COUNT on page 30
Printer web page:
View and Modify Printer Settings > Advanced Setup >
Head Test Count
Table 7 • Print Settings (Continued)

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
