Zebra 105SL Plus User Manual

Printer Configuration and Adjustment
Changing Printer Settings
86
P1056468-002 7/3/13
Maximum
Label Length
Set the maximum label length to a value that is at least 1.0 in. (25.4 mm) greater than the
actual label length plus the interlabel gap. If you set the value to one that is smaller than the
label length, the printer assumes that continuous media is loaded, and the printer cannot
calibrate.
For example, if the label length is 6.0 inches (152 mm) including the interlabel gap, set the
parameter for at least 7.0 inches (178 mm).
Accepted values:
0 to the maximum label length supported by the printer
Related ZPL command(s): ^ML
SGD command used:
none
Control panel menu item:
MAXIMUM LENGTH on page 22
Printer web page:
View and Modify Printer Settings > Media Setup >
Maximum Length
Table 7 • Print Settings (Continued)
2
1
Label length (including interlabel gap)
2
Interlabel gap
3
Set the maximum label length to approximately
this value
1
3

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
