Cutter Mode (Optional)
To insure proper media loading, follow the directions for the Tear-Off
Mode with the exception that the end of the media must be positioned on
top of the platen roller. See Figure 10.
With the end of the media positioned directly on top of the platen roller (a),
close the head open lever. The printer will automatically calibrate, feed out,
and cut the label when the printer is powered on or the printhead is opened
and closed.
NOTES: The cutter only cuts if the printer is in cutter mode. Refer to the
ZPL II Programming Guide or the label preparation software user’s guide
for instructions.
The cutter will cycle once at power up or reset (even when NOT in cutter
mode).
S400 & S600 User’s Guide 11
a
Figure 10
