Ribbon Removal
Refer to Figure 12.
When it’s time to change the ribbon, cut the ribbon where it is stretched
between the upper ribbon guide arm and the takeup spindle. To remove
ribbon from the takeup spindle, press the release button (d) and slide the
ribbon off the spindle.
14 S400 & S600 User’s Guide
a
d
c
b
Figure 12
