Zebra 400 - Media Specifications; Media Handling

Media Specifications
Total
media
width
Minimum 0.75" 19 mm
Maximum 4.5" 114 mm
Maximum (cutter installed) 4.0" 102 mm
Label
length
Minimum
Tear-Off 0.63" 16 mm
Peel-Off 1.00" 25 mm
Cutter 1.50" 38 mm
Maximum See “Printing Specifications”
Total
thickness
(includes
liner)
Minimum 0.0023" 0.058 mm
Maximum (printhead
position may need to be
adjusted above 0.01")
0.012" 0.305 mm
Core size 3.0" 76 mm
Maximum roll diameter 8.0" 203 mm
Inter-label
gap
Minimum
0.08"
(0.118" preferred)
2mm
(3 mm preferred)
Maximum 0.16" 4 mm
Ticket/tag notch size (W x L) 0.08" x 0.48" 2 mm x 12 mm
Media Handling
n
Tear-off mode: Produced in strips
n
Peel-off mode: Dispensed and peeled away from the liner
n
Cutter mode: Printed and individually cut
S400 & S600 User’s Guide 55
63
