Zebra 400 User Manual

Parallel Interface Technical Information
S400 & S600 User’s Guide 61
Parallel Connector Pinouts
Pin. No. Description
1
nStrobe/Host Clk
2-9
Data Bits 1-8
10
nACK/PtrClk
11
Busy/Per Busy
12
PError/ACK Data Req.
13
Select/Xflag
14
nauto Fd/Host Busy
15
Not Used
16-17
Ground
18
+5V @ 1A Fused
19-30
Ground
31
nlnit
32
nFault/nData Avail.
33-34
Not Used
35
+5V through 2.2KΩ Resistor
36
NSelectIn/1284 active
69
