Specifications
NOTE: Printer specifications are subject to change without notice.
NOTE: Your printer may not have all of the options described in these
specifications.
General Specifications
Height 13" 330 mm
Width 8.25" 210 mm
Depth 17" 432 mm
Weight (option-dependent) 17 lbs 7.71 kg
Electrical
Auto range 110 VAC +/-20% or
230 VAC +/-15%, 47-63 Hz
3 Amps @ 110 VAC, 1.5 Amps @ 230 VAC
Agency approvals
UL1950 3rd Edition; CSA22.2 No950-95;
CISPR22-B; EN50082-1:1997; EN60950
Meets FCC Class B and CAN.DOC Class A Rules
Temperature
Operating 40 to 105° F 5 to 40° C
Storage -40 to 140° F -40 to 60° C
Relative
humidity
Operating 20 to 85%, non-condensing
Storage 5 to 85%, non-condensing
Communications
Interface
DB-9S-type RS-232 serial data interface;
110-57,600 baud; parity, bits/char. and XON-XOFF
or DTR handshake protocols -- all software
selectable
Bi-directional parallel data interface
S400 & S600 User’s Guide 53
