Printing Specifications
Printing Specifications S400 Printer S600 Printer
Resolution
203 dots per inch (8 dots per mm)
Dot size (square)
0.005" (0.127 mm)
Maximum print width
4.09" (104 mm)
Print length
Minimum
0.005" (0.127 mm)
Maximum
36" (914 mm) 39" (991 mm)
Bar code modulus (“X”)
dimension
5 mil to 55 mil
Programmable constant
printing speeds
2" (51 mm)
3” (76 mm)
4” (102 mm)
2" (51 mm)
3" (76 mm)
4" (102 mm)
5" (127 mm)
6" (152 mm)
DRAM memory
1MB 2MB
Flash memory (E:)
n/a 1MB
Ribbon Specifications
Ribbon width (we
recommend using ribbon
at least as wide as the
media to protect the
printhead from wear).
Minimum 1.57" 40 mm
Maximum 4.5" 114 mm
Standard
lengths
2:1 media to ribbon roll ratio 984’ 300 m
3:1 media to ribbon roll ratio 1476’ 450 m
Ribbon core inside diameter 1.0" 25 mm
Maximum ribbon roll diameter 3.2" 81 mm
54 S400 & S600 User’s Guide
