Replacing Parts
Replacing the Motor
56
980618-001 A Thermal Transfer G-Series
TM
Service Manual 8/27/08
Installation
1. From beneath, align the motor into place making sure its gears mesh with the transfer
gears and then align the motor’s threaded mounting shafts to the printer chassis.
2. Put a flat washer and M3 nut on the threaded motor mounting shaft farthest away from the
inside of the printer and hand tighten the nut.
3. Place a flat washer, the ground clip and then M3 nut on the other threaded motor. Rotate
the ground clip to rest against the latch cover on the printers chassis. Use a M3 nut driver
to tighten both nuts securing the motor.
4. Reconnect the motor’s ground wire to the Main Logic circuit board. For printers with the
cutter option, reconnect this ground wire to the ‘Y’ connector joining the cutter and motor
ground wires to connect to the Main Logic circuit board.
Replace the bottom case. Reload media. Plug in power, turn on the printer and print a status
report to ensure proper function.
