Cable Routing
Main Printed Circuit Board Assembly
76
980618-001 A Thermal Transfer G-Series
TM
Service Manual 8/27/08
Main Printed Circuit Board Assembly
Figure 1 • Connectors on the Main Logic Board PCBA
Motor
Printhead
Wire Bundle
Ground
Wires
Interfaces
Power Switch
and Input
Optional
Connection
Reflective
Black Line
Sensor
Feed Switch
Gap Sensor
Cable
Head Up
Sensor
Wire Bundle
Dispenser
Wire Bundle
Optional
Connection
Optional
Real-Time Clock
connection
Optional
Connection
Optional
Cutter
