Replacing Parts
Replacing the Cutter (Option)
64
980618-001 A Thermal Transfer G-Series
TM
Service Manual 8/27/08
6. Lower the cutter mechanism forward into the cover; make sure the frame’s top edge fits
under and guide on the cover.
7. From beneath, replace the two screws that secure the cover to the mechanism and use a #1
Phillips screwdriver to tighten them.
Installation of the bezel
1. With the printer upside down, align the cutter so that the mounting holes face the rear of
the printer and the flat media exit faces the top of the printer.
2. Place the screws into the mounting holes.
3. Place the cutter against the printer.
4. Use a #1 Phillips screwdriver to tighten the screws.
5. Plug the ground wire into its post on the Main Logic circuit board.
6. Plug the wire bundle into its connector on the Main Logic circuit board.
Replace the bottom case. Reload media. Plug in power, turn on the printer and print a status
report to ensure proper function.
