Cable Routing
Print Mechanism
72
980618-001 A Thermal Transfer G-Series
TM
Service Manual 8/27/08
Feed/Ribbon
Connector
Feed/Ribbon
Cable
Upper Media
Connector
Dispenser
(Peel)
Feed/Ribbon
pcba
Head Up
Connector
Black Line
Connector
