A - 4 MC55 Integrator Guide
Wireless PAN Data and Voice Communications
Bluetooth Class II, v 2.0 EDR; on-board antenna.
Global Positioning System
GPS SiRF III. On-board antenna.
Data Capture Specifications
Options 1D laser scanner
2D imager
1D laser scanner and color camera
2D imager and color camera
Linear 1D Scanner (SE950) Specifications (MC5574 and MC5590 only)
Optical Resolution 0.005 in. minimum element width
Roll +/- 30° from vertical
Pitch Angle +/- 65° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Sunlight: 8,000 ft. candles (86,112 Lux)
Artificial Light: 450 ft. candles (4,844 Lux)
Shock 2,000 +/- 5% G
Scan Rate 50 (+/- 6) scans/sec (bidirectional)
Scan Angle 46.5° (typical)
Laser Power 1.0 mW nominal
Linear 1D Scanner (SE960) Specifications (MC55A0 only)
Optical Resolution 0.005 in. minimum element width
Roll +/- 35° from vertical
Pitch Angle +/- 65° from normal
Skew Tolerance +/- 40° from normal
Ambient Light Sunlight: 10,000 ft. candles (107,640 Lux)
Artificial Light: 450 ft. candles (4,844 Lux)
Shock 2,000 +/- 5% G
Scan Rate 104 (+/- 12) scans/sec (bidirectional)
Scan Angle 47° (typical)
Laser Power 1.7 mW nominal
Table A-1
MC55 EDA Technical Specifications (Continued)
Item Description
