Zebra MC55 User Manual

Technical Specifications A - 5
2D Imager Engine (SE4400) Specifications (MC5574 only)
Field of View Horizontal - 32.2°
Vertical - 24.5°
Optical Resolution 640 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 50° from normal
Ambient Light Total darkness to 9,000 ft. candles (96,900 Lux)
Shock 2,000 +/- 5% G
Focal Distance from Front of
Engine
Near: 5 inches
Far: 9 inches
Aiming Element (VLD) 650 nm +/- 5 nm
Illumination Element (LED) 635 nm +/- 20 nm
2D Imager Engine (SE4500-SR) Specifications (MC5590 and MC55A0 only)
Field of View Horizontal - 40°
Vertical - 25°
Optical Resolution 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light 9,000 ft. candles (96,900 Lux)
Shock 2,000 +/- 5% G
Focal Distance from Front of
Engine
Near: 5 inches
Far: 9 inches
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm LEDs (2x)
2D Imager Engine (SE4500-HD) Specifications (MC5590 and MC55A0 only)
Field of View Horizontal - 38.4°
Vertical - 24.9°
Optical Resolution 752 H x 480 V pixels (gray scale)
Roll 360°
Table A-1 MC55 EDA Technical Specifications (Continued)
Item Description

Zebra MC55 Specifications

General

Brand	Zebra
Model	MC55
Category	Handhelds
Language	English
