Hardware Troubleshooting
Troubleshooting the Internal ZebraNet 10/100 Print Server
138
P1043301-005 11/21/13
For the ZM400, ZM600, HC100, Xi4, and 105SLPlus Printers
Alongside of the RJ45 connector, there is a single LED containing a red element and a green
element. By turning on and off different combinations of these two LED elements, the LED
indicates Ethernet links, activity, and speed.
For the G-Series, ZP Series, and LP/TLP 2824 Plus Printers
On the top of the RJ45 connector, two LEDs are provided for these printers. The left LED is
green and the right LED is amber. Follow the table below to determine activity and status of
the G-Series, ZP Series, and LP/TLP 2824 Plus printers.
Status LED State Description
Green, solid Print server is working.
Green, flashing For solutions, see Table 22 on page 135.
Red, solid For solutions, see Table 22 on page 135.
Red, flashing For solutions, see Table 22 on page 135.
Alternating Red/Green For solutions, see Table 22 on page 135.
LED State Description
Off No Ethernet link detected
Amber 10 Mbps link detected
Amber, blinking 10 Mbps link detected and Ethernet activity detected
Green 100 Mbps link detected
Green, blinking 100 Mbps link detected and Ethernet activity detected
Left LED State Right LED State Description
Off Off No Ethernet link detected
Off Amber 10 Mbps link detected
Green, blinking Amber 10 Mbps link detected and Ethernet activity
detected
Green Off 100 Mbps link detected
Green Amber, blinking 100 Mbps link detected and Ethernet activity
detected
