Getting Started
Enabling Protocols
72
P1043301-005
1
1/21/13
Enabling Protocols
This section contains directions for accessing protocols using W
ebV
iew
.
Using W
ebView
T
o enable protocols using WebV
iew
, complete these steps:
1.
Open a W
eb browser
.
2.
In the
Address text-box, type your printer
’
s IP address, then press
Enter
.
Y
our browser page looks similar to
Figure
18
.
Figure 18 • Address T
ext-Box
