4-Slot Battery Charger Setup
1. Plug the DC line cord plug into the power port on the back of the charger.
2. Plug the DC line cord connector into the power supply.
3. Plug the AC line cord into the power supply.
4. Plug the AC line cord into an AC outlet.
1 Power Supply
2 AC Line Cord
3DC Power Port
4 DC Line Cord
2
1
4
3
