Zebra TC21 - Installing on the Windshield

fAccessories
150
5.
Remove protective plastic from suction cup.
Installing on the Windshield
To install the cradle on the windshield:
1. Fix the suction cup mount to the selected area with the suction lever facing up.
2. Push the lever towards the base to create a vacuum between the suction cup and the windshield.
1 Mount
2 Nut
3 Rubber Gasket
4 Socket
4
1
3
2
