Zebra TC21 Product Reference Guide

Using the Device
35
Table 5 Status Icons
Icon Description
Alarm is active.
Main battery is fully charged.
Main battery is partially drained.
Main battery charge is low.
Main battery charge is very low.
Main battery is charging.
All sounds, except media and alarms, are muted. Vibrate mode is active.
Indicates that all sounds except media and alarms are muted.
Do Not Disturb mode active.
Airplane Mode is active. All radios are turned off.
Bluetooth is on.
The device is connected to a Bluetooth device.
Connected to a Wi-Fi network. Indicates the Wi-Fi version number.
Not connected to a Wi-Fi network or no Wi-Fi signal.
Connected to an Ethernet network.
Speakerphone enabled.
Portable Wi-Fi hotspot is active (WWAN only).
Connected to a 4G LTE/LTE-CA network (WWAN only)
1
.
Connected to a DC-HSPA, HSDPA, HSPA+, HSUPA, LTE/LTE-CA or WCMDMA
network (WWAN only)
1
.
Connected to a 1x-RTT (Sprint), EGDGE, EVDO, EVDV or WCDMA network
(WWAN only)
1
.
Connected to a GPRS network (WWAN only)
1
Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network (WWAN only)
1
.
Connected to an EDGE network (WWAN only)
1
.
1
Cellular network icon that appears is dependent upon the carrier/network.

Zebra TC21 Specifications

General

Display diagonal	5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1280 x 720 pixels
Battery capacity	3100 mAh
Battery life (max)	10 h
Battery recharge time (off)	4 h
Flash memory	32 GB
Internal memory	3 GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.0
Security algorithms	EAP-PWD, EAP-PEAP, EAP-TLS, EAP-TTLS, LEAP, MSCHAPv2, WEP, WPA, WPA-AES, WPA-TKIP, WPA2, WPA2-AES, WPA2-TKIP
Rear camera resolution (numeric)	13 MP
USB 2.0 ports quantity	1
RFID reader	No
Scanner type	1D/2D
Certification	RoHS 2011/65/EU; 2015/863 REACH SVHC 1907/2006
Product color	Black
International Protection (IP) code	IP67
Speakers	Mono
Operating system version	10
Operating system installed	Android
Number of cores	8
Processor model	660
Processor family	Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	13.7 mm
Width	79 mm
Height	158 mm
Weight	236 g
