Setup
48
Ethernet (LAN, RJ-45)
The printer requires UTP RJ45 Ethernet cable rated CAT-5 or better.
The printer has a built-in network print server. For more information on configuring your printer to run on a
compatible Ethernet based network, see the Wired and Wireless Print Server users guide. The printer
must be configured to run on your network. The print server on board your printer can be accessed through
the printer’s print server Web pages.
Ethernet Status/Activity Indicators
The Ethernet connector on the printer has two (2) status/activity indicators that are partially visible to
provide interface status at the connector.
Ethernet Cable
(RJ45 Connector)
LED Status Description
Both OFF No Ethernet link detected
Green 100 Mbps link detected
Green with the Amber flashing 100 Mbps link and Ethernet activity detected
Amber 10 Mbps link detected
Amber with the Green flashing 10 Mbps link and Ethernet activity detected
