Maintenance
89
Media Path Cleaning
Use a cleaning swab and/or a lint free cloth to remove debris, dust or crust that has built-up on the holders,
guides and media path surfaces. Lightly moisten the swab or cloth with 90% solution isopropyl alcohol. For
hard to clean areas, use extra alcohol on a cleaning swab to soak the debris to break up any adhesive that
may have accumulated on surfaces in the media compartment.
Do not clean the printhead, sensors, or platen as part of this process.
The lower half of these printers these printers get cleaned the same.
1. Wipe the inside surfaces of the roll holders and the underside of the media guides with a cleaning
swabs and wipes.
2. Wipe the movable sensor slide channel (but not sensor). Move the sensor to get to all areas.
3. Wait one minute before closing the printer. Discard used cleaning supplies.
Media
Guides
Media Roll
Holders
Don’t Clean Sensor Window
Clean the sensor channel only
To Next Page
