Zebra ZD200 Series

Maintenance
91
Label Dispenser Option Cleaning
1. Open the door and clean the peel bar, inner surfaces and ridges on the door.
2. Wipe the roller while rotating it. Discard the swab or cloth. Clean again to remove diluted residue.
3. Clean the sensor window. The window should be clear of streaks and residue.
Ridges
Pinch Roller
Peel Bar
Label Taken
Sensor
Inside Wall
