Zeiss Axio Observer 7 - Page 23

DESCRIPTION OF THE DEVICE
Axio Observer Equipment and compatibility table ZEISS
12/2016 431004-7244-001 23
Equipment Option
Axio Observer
3 m 5 m 7 m
Sideport (type)
2 or 3-position, manual (port only on left)
+
- -
2 or 3-position, man. L/R
-
+ -
3-position, mot. L/R
-
- +
Sideport (component)
60N L, 2 switching positions
(100% vis : 0% L / 20% vis : 80% L)
O
O -
60N L 100, 2 switching positions
(100% vis : 0% L / 0% vis : 100% L)
O
O -
60N L, 3 switching positions
(100% vis : 0% L / 0% vis : 100% L /
50% vis : 50% L)
O
O O
60N R, 3 switching positions
(100% vis : 0% R / 0% vis : 100% R /
50% vis : 50% R)
-
O O
60N L/R, 3 switching positions
(100% vis : 0% LR / 0% vis : 100% L /
20% vis : 80% R)
-
O O
60N R/L 100, 3 switching positions
(100% vis : 0% LR / 0% vis : 100% L /
0% vis : 100% R)
-
O O
60N L 80/R 100, 3 switching positions
(100% vis : 0% LR / 20% vis : 80% L /
0% vis: 100% R)
- O O
Path deflection to the tube
(VIS only)
+
O O
Beam path switching (for VIS/front
port/base port)
manual
-
O -
motorized
-
- O
Baseport / frontport
-
O O
Scanning stages
Scanning stage 130x85 CAN
O O O
Scanning stage 130x100 STEP
O
O O
Scanning stage 130x100 PIEZO
O
O O
Holder with LCD display
O**
Carrier for transmitted-light
illumination for HAL 100 lamp and
micro LED
without LCD display
O
- O
with LCD display
-
O** -
Condensers
LD 0.35 / LD 0.55, manual
O
O O
LD 0.55, motorized
-
O O
Axio Imager 0.8/1.4 (s. PL 40.19.04)
O
O O
Shutter for transmitted light
internal
-
O O
external, high speed (with internal control system)
-
O O
Reflected light illuminator
manual
+
1)
O O
motorized
-
O O
Slider for reflected light illuminator
manual
O
O O
motorized
-
O O
Polarizer slider RL 6x30 mm, 90°
rotatable
O O O
