DESCRIPTION OF THE DEVICE
ZEISS Equipment and compatibility table Axio Observer
22 431004-7244-001 12/2016
3.3.2 Axio Observer 3 materials, 5 materials and 7 materials
Equipment Option
Axio Observer
3 m 5 m 7 m
Stand
manual
+
+ -
motorized
-
O* +
Coding PC readable
+
+ +
Display
LCD display
- O** -
TFT display
-
- +
Docking station
-
- O
Interfaces
CAN
+
+ +
RS 232
-
+ +
USB
+
+ +
TCP/IP
-
+ +
Socket for external UNIBLITZ shutter
-
+ +
Trigger socket (IN/OUT) for shutter
-
+ +
4-position CAN hub
O
O O
Light Manager
+
+ +
Contrast Manager
-
- +
Control ring
right
-
+ +
left
-
- +
Z-focus drive
manual (2 mm / 0.2 mm)
+
+ -
motorized, stepper motor drive (z-step size 10 nm)
-
- +
Adjustable vertical stop
for Z drive (focus stop)
manual
-
+ -
Automatic Component Recognition
(ACR)
Nosepiece ACR
-
- +
Reflector turret ACR
-
O O
Power supply unit
internal
+ + -
external
-
- +
Z drive control (flat control knob)
right
O
- O
left
O
+ O
Z drive extended travel range
(13 mm)
manual
O
O -
motorized
-
- O
Nosepiece
6 position HD DIC cod.
+
+ -
6 position HD DIC mot. ACR
-
- +
Compensator mount 6x20
+
+ +
Tube lens mount, fixed / Optovar
turret
Tube lens mount, 1-position, fixed
+
O O
Optovar turret 3-position, coded
-
O -
Optovar turret 3-position, mot.
-
- O
