Zenoah GZ3500T Workshop Manual

10 – English
Displacement Cylinder diameter Length of stroke Max. output/speed
cm
3
/cubic inch Ømm/Øinch mm/inches kW/hp/rpm
GZ3500T 35.235 / 2.15 40 / 1.57 28 / 1.10 1.5 / 2.0 / 9,500
Electrode gap Ignition system Air gap Carburettor type
mm/inches mm/inches
GZ3500T 0.5 / 0.02 Ikeda Denso 0.3 / 0.012 Walbro WT 804
Usable cutting length Chain speed at Chain pitch Drive links
cm/inch max. output - speed mm/inches mm/inches
m/s - rpm
GZ3500T 30-36/12-14 19.1 / 9,500 3/8” /9.52 1.3 / 0.050
3 Technical data
Technical data
