24 – English
Safety equipment
2
Insert the throttle actuator rod into the carburettor.
Fig 33
Fig 34
Fig 35
6.10 Assembling the throttle lockout,
throttle and spring
1
Put the electrical cables J back in the cable slot as
shown in gure 32.
Fig 32
3
Fold the throttle actuator rod forwards so that it can
be placed in the handle part.
4
Push the carburettor into place and make sure
the nipple is securely pushed down in the intake
connector. Push the cover for the choke outlet into
place.
