English – 21
Safety equipment
6.6 Dismantling the start/stop switch
1
Bend the start/stop switch loose with a screwdriver,
see gure 22.
2
Check that the start/stop switch is intact.
Cleaning and checking
Clean and check carefully all components. If there
are cracks or other defects, these details should
be replaced with new ones. Always use original
spare parts.
Fig 22
6.7 Assembling the start/stop switch
1
Attach the cables, see gure 23.
2
Push the start/stop switch into the slot.
Fig 23
Fig 24
Attach cables A and B, which come from the ignition
coil on the plates on the stop switch, see gure 24.
