Fig 36
5
Hook the throttle actuator rod E to the throttle, put
the spring back onto the throttle. Place the throttle
and the spring in the handle part as shown in
gure 36. Ret the electrical cables H in the slot as
shown in gure 36.
Fig 37
Fig 38
Fig 39
6
Place the throttle as shown in gure 37. Put the
handle bar in the handle unit.
7
The handle part is fastened with the screws A, see
gure 39. Note! Hold the throttle lockout down so
that the spring doesn’t jump out when the handle
part is assembled.
8
Ret the guide F, see gure 39. Fasten the air lter
holder with the air lter, then fasten the air lter
cover. Make sure the lock is open when you push
the cover into place.
