11
RECORD - used for programming memories and submasters.
COPY - used to copy items from one location to another (eg memories, submasters, groups, palettes etc.) Holding
down SHIFT and pressing COPY is used to transfer a memory onto a submaster.
INSERT - used to insert point memories, add or insert chase steps or add or insert duplicates when patching dimmers
and xtures.
DELETE - used when deleting items (memories, submasters, groups, palettes etc.)
ENTER - used for completing commands and selecting ‘soft’ buttons on the Main LCD, monitor screens and popup
windows.
HOME - used as a quick method for setting all the parameters, or all the parameters for a particular attribute to their
home values. The Home values are found in the Edit Fixtures table in Setup and can be adjusted as required.
GRAND MASTER - controls the nal output values of all dimmer and xture intensity channels, resulting from the
Program Window, Playback X and submasters. The Grand Master level is displayed on the monitor screen.
BLACKOUT - reduces the outputs of all dimmer and xture intensity channels to zero. Pressing the BLACKOUT key
toggles between active and not active. The red LED in the BLACKOUT key ashes when blackout is active.
SHIFT - used in conjunction with various front panel controls to provide additional functions, eg holding SHIFT and
pressing the COLOUR key displays the Colour Palette Window on the monitor.
Figure 9 - Multi Function Faders
