Zetor Major 80 User Manual

140
MAIN TECHNICAL PARAMETERS
MAIN TRACTOR´S PARAMETERS (mm)
Note
Turning-circle diameter length
- without ballast weights in front of cab’s grill 3 930
- with ballast weight in front of cab’s grill 4 230
Width over rear fenders 1 840
Height to the mouth of exhaust pipe 2 578
Height of tractor to upper cab’s rim 2 624
Clearance height under the girder of front
axle 393
Height of nozzle of multistage suspension
linkage in its topmost position (the centre of
nozzle ) 890/840/790/690
Height of swinging draw bar (on internal
bottom fork surface) 418/455
Rear PTO shaft height 725
Wheel base 2 200
TRACTOR´S WEIGHT
Tractor’s weight (kg) 3090
e

Zetor Major 80 Specifications

General

Engine Power	75 HP
Hydraulic System	Open center
Rated speed	2200 rpm
Max. speed	30 km/h
3-point hitch	Category II
PTO Speed	540/1000 rpm
Transmission	12F + 12R
Engine	Zetor
Displacement	4, 156 cc
Hydraulic pump capacity	50 l/min
Engine Type	Diesel
Wheelbase	2332 mm
