UNItivity 5000 Specifications
User Manual
Copyright © 2022 Zinwave. All rights reserved. 15-1
15 Specifications
System RF Parameters
System Bandwidth (Part No.
305-XXXX)
150 MHz to 2700 MHz
System Bandwidth (Part No.
306-XXXX)
3300 MHz to 4200 MHz
System Band Gain Flatness
±1 dB
In any 100 MHz band
Wideband Gain Flatness
-5 dB / +1 dB
Downlink
Gain (Part No. 305-0XXX)
25 dB (max)
1dB steps
Gain (Part No. 305-1007)
(higher power remote has
increased gain)
29 dB (max)
1 dB steps
Gain (Part No. 306-XXXX)
29 dB (max)
1dB steps
RF Input Power to Service
Module
-25 dBm (min) to
+15 dBm (max)
Working input power to Service Module
RF output power at Remote
Unit Tx port (Part No. 305-
0007)
+20 dBm/+18 dBm
Composite Power at Remote Unit Output for
services approved to FCC / CE
RF output power at Remote
Unit Tx port (Part No. 305-
1007)
+20 dBm/+18 dBm (F < 1575
MHz) and simultaneously
+23 dBm/+21 dBm (F > 1575
MHz)
Composite Power at Remote Unit Output for
services approved to FCC / CE
RF output power at Remote
Unit Tx port (Part No. 306-
0007)
+22 dBm
Composite Power at Remote Unit Output for
services approved to CE
Uplink
Gain (Part No. 305-0XXX)
25 dB (max)
1 dB steps
Gain (Part No. 305-1007)
(higher power remote has
increased gain)
29 dB (max)
1 dB steps
Gain (Part No. 306-XXXX)
29 dB (max)
1 dB steps
RF input level to Remote Unit
Rx port
+10 dBm (max)
Overload condition. Signal internally limited
to -20dBm max by Remote Unit Uplink AGC
RF output power from Service
Module
+5 dBm (max)
Output power of Service Module in Hub
Fiber Optic
Number of optical ports
Up to 8 duplex ports supported on Primary Hub (Optical Modules); 9 duplex
ports on Secondary Hub; 1 duplex port on Remote Unit; SC-APC / SC-APC
connectors
Wavelength
1310 nm
