Ports of C2-260/inBio2-260 Control Panel:
Connection with Door Sensors, Exit Switches, Auxiliary 3.5
Input Devices, and RS485 Extension Communication
1. Door sensor
A Door Sensor is used to sense the open/close status of a door. With a door sensor switch, an access
control panel can detect the unauthorized opening of a door and will trigger the output of alarm.
Moreover, if a door is not closed within a specified period after it is opened, the door control panel will
also raise the alarm. It is recommended to select two-core wires with a gauge over 0.22 mm
2
. A door
sensor can be omitted if it is unnecessary to monitor the open/closed status of a door, raise the alarm
when the door is not closed for a long time, monitor if there is unauthorized access, and use the interlock
function.
No. Functional Port
C2-260
(Two-Door Two-Way)
inBio2-260
(Two-Door Two-Way)
1 Exit button
2 2
2 Control lock relay
2 2
3 Door Sensor
2 2
4 Auxiliary Input
2 2
5
Auxiliary Output
2 2
6
RS485 Reader
4 4
7
FR1200 Reader
0 4
8
RS485 Extension
Communication
 
9 TCP/IP
 
