C2-260/inBio2-260 Access Control Panel
User Manual
Page | 28 Copyright©2020 ZKTECO CO., LTD. All rights reserved.
5. The default IP address of the access device may conflict with the IP of a device on the local
network. You can modify its IP address: click Modify IP Address, and a dialog box will pop up in
the interface. Enter the new IP address and other parameters (Note: Configure the gateway and
IP address in the same network segment).
Note: Some PUSH devices support SSL. To use this function, select the HTTPS port during software
installation and ensure that the device firmware supports SSL.
5.4.2 I/O Board
On the device module, click Device > I/O Board > New to add the I/O Board device to the software.
Enter the name of the I/O Board. Select the Device by clicking the Device Name field. The device list
appears, as shown below:
To Next Page
