As an All-in-One device, you can connect it to an external RS485 reader. When it is used as an RS485
reader, it needs to be used with a 6-bit DIP switch. The first to fourth ports are used to set the RS485
address, port 5 is used to switch modes, port 6 is to set the state of terminal resistor.
Switch Modes Port Switch Settings
All-in-one &
Wiegand reader
5
ON
RS485 Reader
5
OFF
