7. Interface of Parameter Setting Mode
No. Functions Description Range Changing Default
Step Setting
1：ON
After sewing, the presser doesn’t
rise until the cloth-feeding board
moves to the position for laying
cloth; during the process of
searching origin, the presser
keeps going down when each axis
return to origin. The presser
doesn’t rise until the frame goes
to the position for laying cloth.
U057
Enable clamp at
test
0：OFF
The raise of presser is forbidden
in test mode
1：ON
In Test mode, the following
operations can make presser go
up：
（A）：Manual switch type or
double pedal type: press presser
switch
（B）：pedal type：return to pedal
In restarting the test mode, the
following operations have to be
done for lowering the presser
（A）：Manual switch type or
double pedal type: press presser
switch
（B）：pedal type：return to pedal
0~1 1 0
U058
Keep clamp down
after sewing
0：Up
Presser goes up when the
automatic sewing is finished
1：Down
Presser keeps going down when
the automatic sewing is finished.
Please perform the following
operations when the presser rise:
（A）：Manual switch type or
double pedal type: press presser
switch
（B）：pedal type：return to pedal
0~1 1 0
U150
Stop at n. up when
suspended
OFF：At pause, the upper axis is
in the status of emergency stop
ON：At pause, the upper axis
stop at needle upper position
0~1 1 1
U152
Final stch spd
main shaft
Set speed of the last stitch
700~900 10rpm 800
U153
Last speed main
shaft
Set the stop speed
250~450 10rpm 350
U156
Stop angle main
shaft
The stop control section will be
prolonged when this value goes
up.
2.5~17.5 0.5° 11.0
U256
Interval of origin
detect
0：OFF
Do not detect origin after sewing
0~9 1 0
