ZOLL 330 - Performance Tests

Performing Maintenance Tests
1-4 www.zoll.com 9650-000278-01 Rev. B
2.0 Performance Tests
Instructions
1. Power on the aspirator.
2. Select “Continuous” Mode and “Surgical” procedure from the parameter buttons.
3. In the order listed under Test Results, set the aspirator to each vacuum target indicated by the
table. Record the vacuum level as indicated by the Calibrated Pressure Gauge and the
aspirator in the table. Record a Pass or Fail for each result.
4. Repeat all vacuum measurements with “Smart Flow” set to “OFF.”
Note: Performance Tests must be performed in the order presented below. The CASS
procedure parameter button must be selected to test at 20 mm Hg.
Testing
Vacuum Setting Calibrated Pressure Gauge
Measurement
Aspirator Vacuum Display
Result
Pass Criteria Vacuum Setting ± (8 % of Setting + 2
mm Hg)
Measured Vacuum ± (8 % of Setting
+ 2 mm Hg)
Smart Flow: ON Pass / Fail
2.2 550 (Max) mm Hg Pass Range:(504-596) Pass Range:(504-596)
o o
2.3 20 mm Hg Pass Range:(16.4-23.6) Pass Range:(16.4-23.6)
o o
2.4 400 mm Hg Pass Range:(366-434) Pass Range:(366-434)
o o
2.5 50 mm Hg Pass Range:(44-56) Pass Range:(44-56)
o o
2.6 200 mm Hg Pass Range:(182-218) Pass Range:(182-218)
o o
2.7 90 mm Hg Pass Range:(80.8-99.2) Pass Range:(80.8-99.2)
o o
2.8 110 mm Hg Pass Range:(99.2-120.8) Pass Range:(99.2-120.8)  Pass  Fail
Smart Flow: OFF Pass / Fail
2.9 550 (Max) mm Hg Pass Range:(504-596) Pass Range:(504-596)
o o
2.10 20 mm Hg Pass Range:(16.4-23.6) Pass Range:(16.4-23.6)
o o
2.11 400 mm Hg Pass Range:(366-434) Pass Range:(366-434)
o o
2.12 50 mm Hg Pass Range:(44-56) Pass Range:(44-56)
o o
2.13 200 mm Hg Pass Range:(182-218) Pass Range:(182-218)
o o
2.14 90 mm Hg Pass Range:(80.8-99.2) Pass Range:(80.8-99.2)
o o
2.15 110 mm Hg Pass Range:(99.2-120.8) Pass Range:(99.2-120.8)
o o
