Replacement Part Installation
3–10 www.zoll.com 9650-000278-01 Rev. B
15 Re-install the front case assembly. Clean screws and apply Vibra-Tite to the 4-40 x 1/
4 screws, insert the screws into the center of the dovetail mounting bracket and
tighten.
Torque: 5 in lbs
Bit Size: #1 Phillips
16 Reconnect the ribbon cable to the PIM board, and then press down on the two locking
tabs (ears) to lock down the cable connector.
17 Attach the back cover to the aspirator module and align cover with handle, exhaust
muffler housing, and dovetail mounting studs.
Clean screws and apply Vibra-Tite to each screw, then insert and loosely thread
screws in a crossing pattern. Tighten screws in a crossing pattern, then tighten the
two 10-32 Keps nuts and the four 6-32 x 2” screws.
Torque: 6-32 x 2” screws to 9 in lbs, 10-32 Keps Nuts to 18 in lbs
Bit Size: #2 Phillips for screws. 3/8 in nut driver
18 Tighten the four 8-32 x 3 screws on the exhaust muffler.
Torque: 14 in lbs
Bit Size: #2 Phillips
Note: Before tightening the screws, make sure that the Exhaust Muffler Baffle is
aligned so that the “long side”, found on the top of the baffle is on the left, and the
“short side” is on the right, then place the baffle on the Exhaust Muffler Block.
19 Perform calibration and functional test to confirm proper aspirator operation.
Step Action
