Replacement Part Installation
3–26 www.zoll.com 9650-000278-01 Rev. B
20 Tighten the four 8-32 x 3 screws on the exhaust muffler.
Torque: 14 in lbs
Bit Size: #2 Phillips
Note: Before tightening the screws, make sure that the Exhaust Muffler Baffle is
aligned so that the “long side”, found on the top of the baffle is on the left, and the
“short side” is on the right, then place the baffle on the Exhaust Muffler Block.
21 Perform calibration and functional test to confirm proper aspirator operation.
Step Action
