OPERATING ENVIRONMENTS
6-6 www.zoll.com 906-0731-01-05 Rev. C
Warning! The unit is shipped with both the pediatric/adult and infant/pediatric single limb
circuits. A Check Valve (704-0700-01) is required with these breathing circuits when
operating in a hazardous environment. The correct mating of the Check Valve with the
breathing circuit is shown below. Operators who anticipate use in these environments
should also stock the Check Valve.
Check Valve Connection To Breathing Circuit
