Pressure Management
The following table gives the options and ranges for pressure management.
Parameter Window Options /
Range
Availability/Notes Models
Primary
Value
PIP
cm H2O
10 to 80 Volume Target: Measurement
Pressure Target: Control Set-
ting
PIP values greater than 60 cm
H2O require the operator to
perform a separate
confirmation.
All
Secondary
Value
PEEP 0 to 30 AC Modes (ACV, SIMV, CPAP,
BL Modes
All
3 to 30
PS 0 to 60 Spontaneous Breaths
(SIMV and CPAP )
EPAP 3 to 30 Spontaneous Breaths
BL
All
IPAP 6 to 60
Alarm Limits High PIP 20 to 100 PEEP cannot be within 5 cm
H
2
O of the PIP High Limit
setting.
All
Low PIP 3 to 35, Off All
Measured
Value
Mean Airway Pres-
sure
MAP
0 to 99.9 All
Paw Waveform 0 to 100 All
PIP Context Menu All
BreathTrigger
(Assisted,
Spontaneous)
Default:‐2
-6 to -0.5
AdjustmentIncrements:.5 All
