USING THE ZOLL VENTILATOR
4-14 www.zoll.com 906-0731-01-05 Rev. C
SpO2 Parameter Values
Pressing the SpO2 parameter button highlights the Low SpO
2
Alarm Limit and enables its
value to be changed. The default low SpO
2
value at start up is 94%. The SpO2 parameter uses
the same Context Menu as the HR parameter.
The following table gives the options and ranges for the SpO2 parameter:
Parameter Window Options /Range Availability/Notes Models
Primary Value SpO2
%
84 to 100
Measurement
All
Secondary
Values
Not Applicable
Alarm Limits Low Limit
Measured
Values
Pleth
Waveform
86 to 99, Off
SpO2 Context Menu (note same
as HR Context Menu)
Pulse Ox Default :
Standby
Standby, Off,
On
All
Fast SAT Default : Off Off/On
Fast SAT enables rapid tracking of
arterial oxygen saturation changes by
minimizing the averaging. This mode is
clinically applicable during procedures
when detecting rapid changes in SpO
2
is paramount such as induction,
intubation, and sleep studies.
Sensitivity Norm Max
Norm adjusts the pleth signal
sensitivity. Max interprets and displays
data for even the weakest of signals.
Max is recommended during
procedures and when clinician and
patient contact is continuous.
APOD Off Off, On
When on, this mode improves detection
of the "probe off patient" condition, but
reduces the ability to acquire a reading
on patients of low perfusion.
Averaging 8 Seconds 2 to 4, 4 to 6,
8, 10, 12, 16
Seconds
Adjusts the SpO2 and HR averaging
durations.
