906-0731-01-05 Rev. C ZOLL Ventilator Operator’s Guide D-3
Contents of Pediatric/Adult, 6 ft patient circuit package:
• 72” (1.83 m) Ventilator Wye Breathing Circuit, with cut-to-size tube and exhalation valve
• Exhalation drive line (Clear) with connector
• Pressure line (Green) with connector
Pediatric/Adult, 12 ft Patient Circuit
The Pediatric/Adult, 6 ft patient circuit (REF 820-0106-XX) has the following specifications:
• Internal Diameter: 22 mm
• R
INSP
@ 30 Lpm: 0.02 hPa/l/min
• R
EXP
@ 30 Lpm: 0.10 hPa/l/min
• C
T
@ 60 hPa: 2.8 ml/hPa
• Deadspace: 22 ml
• Maximum Working Pressure: 100 hPa (cm H
2
O)
Complies with ISO 5367. Breathing Tube intended for use with Anesthetic Apparatus and
Ventilators.
Non-Sterile - For Single Patient Use Only
Not intended for use with heated humidification.
-40°C to 70°C (-40°F to 158°F)
Caution During use circuit may come into contact with biohazard material. Handle carefully to avoid
cross-contamination.
Contents of Pediatric/Adult, 6 ft patient circuit package:
• 144” (3.65 m) Ventilator Wye Breathing Circuit, with cut-to-size tube and exhalation valve
• Exhalation drive line (Clear) with connector
• Pressure line (Green) with connector
Warning! Compressible volume can significantly decrease the delivered minute ventilation of
small adults and pediatric patients. When managing patients at risk, always correct for
compressible volume following Step 6 in the following “Directions for Use” section of
this appendix.
Warning! Do not use this circuit with PEEP settings below 5 cm H
2
O.
Warning! Given the additional length of the 12ft circuit, the system may not be able to trap PEEP
in patients with short expiatory time. Always ensure that the device is performing as
required.
