Names of parts
05
H6 Handy Recorder
Right (back)
XLR TRS
Bottom
Input 3
MIC/LINE input jack
(supports plug-in power)
Input 4
Battery cover (back)
Speaker (back)
Scroll button
Up and down
Select menu items
Press: Confirm menu
selection
LINE OUT jack
Strap holes
(can also be used with camera straps)
REMOTE jack
MENU button
Press:
Open menu,
Return to last screen
USB jack
1: GND
2: HOT
3: COLD
TIP: HOT
RING: COLD
SLEEVE: GND
