Zoom H6 User Manual

Other functions
Using VU meters to check input levels
89
H6 Handy Recorder
Using VU meters to check input levels
1. Press .
2. Use
to select
“INPUT&OUTPUT”,
and press
.
3. Use
to select
“VU Meter”,
and press
.
4. Use to adjust input
levels and check them
here.
5. Use
to adjust the reference that is used for 0VU.
HINT
The reference level can be set between –20 dBFS and –10
dBFs. The dBFS unit represents the loudness of the signal
in dB with 0 dBFS being the maximum recordable value for
the digital data.
The virtual VU meters can be used to check input levels.

Zoom H6 Specifications

General

Sample rate	96 kHz
Audio quality	24 bit
Frequency range	44100 - 96000 Hz
USB 2.0 ports quantity	1
Product color	Black
USB powered	Yes

Weight and Dimensions

Weight	280 g
Dimensions (WxDxH)	77.8 x 152.8 x 47.8 mm
