Zte ZXR10 8900 Series Hardware Manual

ZXR108900SeriesHardwareManual
interfaces,implementsL2-L7packetprocessing,showslarge
entrysizeandprovidesenhancedMPLSfunctionsoastomeet
complicatedapplicationsinactualnetworking.
FrontPanelFrontpanelisshowninFigure69.
FIGURE69FRONTPANELOFRS-89S3-4XGE-XFP
InterfacesOpticalmoduleusedbyRS-89S3-4XGE-XFPcardishot—swapXFP
opticalmodule.Eachportsupportsdifferenttransmissiondis-
tances.CharacteristicsareshowninT
able126.
TABLE126INTERFACECHARACTERISTICSOFRS-89S3-4XGE-XFPCARD
InterfaceType
Characteristics
10GBASE-SR
XFP-M300
LCconnector ,single-modeber .Wavelength:
850nm.Max.transmissiondistance:300m
Transmittingpowerrange:-7.3dBm~-1dBm;
receivingsensitivity:≥-11.1dBm
10GBASE-LR
XFP-L10K
LCconnector ,single-modeber .Wavelength:
1310nm.Max.transmissiondistance:10Km
Transmittingpowerrange:-6dBm~-1dBm;
receivingsensitivity:≥-10.3dBm
10GBASE-ER
XFP-L40K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:40km
Transmittingpowerrange:-2dBm~1dBm;
receivingsensitivity:≥-11.3dBm
LEDTypeThereare8indicatorsonfrontpanelofRS-89S3-4XGE-XFPcard.
TheirfunctionsareshowninT able127.
TABLE127LEDFUNCTIONSOFRS-89S3-4XGE-XFPCARD
LEDType
StateDescription
LINKIndicator
On:interfacelinkiscreated
Off:interfaceisdisconnectedfromothers
ACTIndicator
Flash,thereisnopacketbeingreceivedor
sentonthisport
Flash:datatransmissionandreceptiononthe
interface
96CondentialandProprietaryInformationofZTECORPORATION

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
