Zte ZXR10 8900 Series - RS-89 S2 A-24 GE-SFP4 RJ Card; Figure 45 RS-89 S2 A-24 GE-SFP4 RJ Front Panel

ZXR108900SeriesHardwareManual
TABLE73RS-89S2-24GE2XGE-RJ4SFPXFPCARD10GOPTICAL
INTERFACELEDFUNCTIONDESCRIPTION
LEDType
StateDescription
ACT
Off:theportisdisconnectedfrom
others
Flash:datatransmissionand
receptionontheport
LINK
On:portlinkiscreated
Off:theportisdisconnectedfrom
others
RS-89S2A-24GE-SFP4RJCard
FunctionRS-89S2A-24GE-SFP4RJcardisa24–portgigabitEthernetoptical
interfacecardandimplementsL2–L7packetprocessingsoasto
meetcomplicatedapplicationsinnetworking.
FrontPanelFrontpanelisshowninFigure45.
FIGURE45RS-89S2A-24GE-SFP4RJFRONTPANEL
InterfacesRS-89S2A-24GE-SFP4RJcardhas24opticalinterfaces,providing
241000BASE-Xservicesor24100BASE-FXservices.Thelast4
opticalinterfacescanalsobeconguredtoelectricalinterface,pro-
viding10/100/1000BASE-Tinterface.
Allopticalmoduleusedbyinterfacearehot—swapSFPoptical
module.Eachportsupportsvarioustransmissiondistancesofgi-
gabitEthernet.ElectricalinterfaceisRJ45interface.Interface
characteristicsareshowninTable74.
TABLE74INTERFACECHARACTERISTICSOFRS-89S2A-24GE-SFP4RJ
CARD
InterfaceType
Characteristics
1000Base-SX
(SFP-M500)
LCconnector ,50or62.5125mmmulti-mode
ber ,withthewavelengthof850nm,maximum
transmissiondistanceis500m
Transmissionpower:-9.5dBm~-4dBm,
receivingsensitivity:<-18dBm
1000Base-LX
(SFP-S10K))
LCconnector ,8or9125mmsingle-modeber ,
withthewavelengthof1310nm,maximum
transmissiondistanceis10km
Transmissionpower:-9.5dBm~-3dBm,
receivingsensitivity:<-20dBm
