ZXR108900SeriesHardwareManual
InterfaceType
Characteristics
1000BASE-LHSFP-S80K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
80km
Transmittingpowerrange:0dBm~5dBm;
receivingsensitivity:≥-22dBm
1000BASE-LH
SFP-S120K
LCconnector ,single-modeber .Wavelength:
1550nm.Max.transmissiondistance:
120km
Transmittingpowerrange:5dBm~9dBm,
receivingsensitivity:≥-30dBm
LEDTypeThereare48LEDsonthefrontpanelofRS-89H1-48GE-SFPcard.
EachinterfacecorrespondstooneLED.FunctionsoftheseLEDs
aredescribedinTable101.
TABLE101LEDFUNCTIONSOFRS-89H1-48GE-SFPCARD
LEDType
StateDescription
LINK/ACT
On:interfacelinkiscreated
Off:interfaceisdisconnectedfromothers
Flash:datatransmissionandreceptionin
theinterface
RS-89H1-48GE-RJCard
FunctionRS-89H1-48GE-RJcardimprovesL2/3functionsbasedon
RS-89S2-48GE-RJcard,showslargeentrysizeandprovidesMPLS
function.Itcanprovide48gigabitEthernetelectricalinterfaces
andimplementL2-L7packetprocessingtomeetcomplicated
applicationsinactualnetworking.
FrontPanelFrontpanelisshowninFigure58.
FIGURE58FRONTPANELOFRS-89H1-48GE-RJ
InterfacesAll48interfacesonRS-89H1-48GE-RJsupportRJ45electricalin-
terface.Eachportsupportsdifferenttransmissiondistancesused
bygigabitEthernet.InterfacecharacteristicsareshowninT
able
102.
82CondentialandProprietaryInformationofZTECORPORATION
