Chapter6
FanPlug-inBox
TableofContents
FanPlug-inBoxOverview.................................................107
FanPlug-inBoxofZXR108912.........................................107
FanPlug-inBoxofZXR108908.........................................109
FanPlug-inBoxofZXR108905.........................................110
FanPlug-inBoxofZXR108902.........................................111
FanPlug-inBoxOverview
ZXR108900seriesswitchadoptsleftsideindraftheatdissipation
mode.Thismodeisadaptedattheleftsideoffrontviewinthe
chassis.Multiplefansareusedtodrafttheairfrominsidethede-
vice.Thereisanairinletthatliesattherightsideofthechassis,
duetowhichtheheatowsfromrighttoleft.Faninsidethede-
viceabsorbstheairfromoutsideandexchangesitwiththeheat
generatedfromsingleboardandthepowerboardofthedevice.
Majorheatingchipsadoptsaluminumradiator .Air-lterissetat
theinletthatfacilitatesthemaintenanceandcleaningofchassis.
Air-ltercanbedisassembledfromthebackofchassis.
FanPlug-inBoxofZXR10
8912
Thereareeightfansinthefanplug-inbox.Frontpanelviewof
fanplug-inboxisshowninFigure79.
