Zte ZXR10 8900 Series Hardware Manual

Chapter4HardwareBoard
LEDsThereare16LEDsinfrontpanelofRS-89S2-12GE-RJ4SFPcard.
EachinterfacehasoneLED.FunctionsoftheseLEDsaredescribed
inTable49.
TABLE49LEDFUNCTIONOFRS-89S2-12GE-RJ4SFPCARD
LEDType
StateDescription
LINK/ACT
On:interfacelinkiscreated
Off:interfaceisdisconnectedfromothers
Flash:datatransmissionandreceptionintheinterface
RS-89S2-24GE-RJCard
FunctionRS-89S2-24GE-RJcardprovides24gigabitEthernetelectricalin-
terfaces.ItisimprovedonthebaseofRS-89S1-24GE-RJcard
tosupportthefunctionsinLayer2andLayer3.Itcanprocess
packetsfromL2toL7tomeetthecomplexapplicationinpractical
networking.
FrontPanelFrontpanelisshowninFigure35.
FIGURE35FRONTPANELOFRS-89S2-24GE-RJ
InterfacesTwenty-fourinterfacesinthefrontpanelofRS-89S2-24GE-RJcard
supportRJ45electricalinterface,supportingdifferenttransmission
distancesusedbygigabitEthernet.
InterfacecharacteristicsofRS-89S2-24GE-RJcardaredescribed
inTable50.
TABLE50INTERFACECHARACTERISTICSOFRS-89S2-24GE-RJCARD
InterfaceType
Characteristics
10/100/1000
Base-TX
FollowIEEE802.3zstandard
RJ45connector
UsingUTP5
Themaximaltransmissiondistanceis100m
MDI/MDIX
LEDsThereare24LEDsinthefrontpanelofRS-89S2-24GE-RJcard.
EachinterfacehasoneLED.FunctionsoftheseLEDsaredescribed
inTable51.
CondentialandProprietaryInformationofZTECORPORATION51

Zte ZXR10 8900 Series Specifications

General

Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% (non-condensing)
Storage Humidity	5% to 95% (non-condensing)
Ports	10/100/1000BASE-T
Layer Support	Layer 2 and Layer 3
VLAN Support	4K VLANs
QoS	8 priority queues per port
Management	CLI, Web, SNMP, RMON
Power Supply	AC or DC
Redundancy	Power supply redundancy, fan redundancy
